| Number of Spindles | 1 |
|---|---|
| Process Type | BTA |
| Hole Location | Off-Center |
| Workpiece Shape | Cylindrical, Cubic |
| METRIC SPECIFICATIONS |
|
| Hole Diameter Min (mm) | 20 |
| Drill Diameter Max (mm) | 102 |
| Hole Diameter Max (mm) | 108 |
| Hole Depth Max (mm) | 2000 |
| Workpiece dimensions (mm) | 2000 |
| Workpiece weight max (kg) | 15000 |
| IMPERIAL SPECIFICATIONS |
|
| Hole Diameter Min (in) | 0.79 |
| Drill Diameter Max (in) | 4.02 |
| Hole Diameter Max (in) | 4.25 |
| Hole Depth Max (in) | 78.74 |
| Workpiece dimensions (in) | 80 |
| Workpiece weight max (lbs) | 33075 |
