Find A Machine by Drilled Hole Diameter
Use the following chart to find machines that meet drilled hole diameter requirements.
Hole Diameter (mm) | Series Description |
---|---|
1 – 6 mm | UNE6 – Precision gundrilling machines specifically for small medical applications UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling |
6 – 20 mm | UNE – Compact gundrilling machines for job shop environments UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tube-sheet applications |
20 – 50 mm | UNE – Compact gundrilling machines for job shop environments UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tube-sheet applications USC-M – Column-type BTA, gundrilling, and milling center for mold manufacturing B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center |
50 – 100 mm | USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tub-sheet applications B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center B-Series > 800 mm swing – BTA drilling machines for longer workpieces, drilled on-center |
100 – 300 mm | B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center B-Series > 800 mm swing– BTA drilling machines for longer workpieces, drilled on-center |
300 – 1,000 mm | B-Series > 800 mm swing – BTA drilling machines for longer workpieces, drilled on-center |
Hole Diameter (inch) | Series Description |
---|---|
0.04 – 0.24 in | UNE6 – Precision gundrilling machines specifically for small medical applications UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling |
0.24 – 0.80 in | UNE – Compact gundrilling machines for job shop environments UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tube-sheet applications |
0.80 – 2.00 in | UNE – Compact gundrilling machines for job shop environments UNI – High production BTA or gundrilling machines with high customization USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tube-sheet applications USC-M – Column-type BTA, gundrilling, and milling center for mold manufacturing B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center |
2.00 – 4.00 in | USK – Knee-type gundrilling machines for on- or off-center drilling USC – Column-type BTA machines for off-center drilling of larger workpieces USC-TS – Column-type multi-spindle drilling for tub-sheet applications B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center B-Series > 800 mm swing – BTA drilling machines for longer workpieces, drilled on-center |
4.00 – 12.00 in | B-Series < 800 mm swing – BTA drilling machine for round workpieces, drilled on-center B-Series > 800 mm swing – BTA drilling machines for longer workpieces, drilled on-center |
12.0 – 40.0 in | B-Series > 800 mm swing – BTA drilling machines for longer workpieces, drilled on-center |
